## Extension: Extension CRLF-較低放射劑量臨床標靶體積、劑量以及治療次數

Official URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-EBRT-RTL | Version: 0.1.0
Active as of 2024-09-01 | Computable Name: CRLFEBRTRTL

用於表示癌症登記長表資料檔(CRLF)之較低放射劑量臨床標靶體積、劑量以及治療次數

Context of Use

This extension may be used on the following element(s):

- Element ID Procedure

Usage info

Usage:

- Use this Extension: Procedure CRLF-體外放射治療資料

### Formal Views of Extension Content

Description of Profiles, Differentials, Snapshots, and how the XML and JSON presentations work.

- Differential Table
- Snapshot Table
- Statistics/References
- All

This structure is derived from Extension

Name | Flags | Card. | Type | Description & Constraints
--- | --- | --- | --- | ---
Extension |  | 0..* | Extension | 最高放射劑量臨床標靶體積、劑量以及治療次數
extension |  | 3..* | Extension | Extension
Slices for extension |  |  |  | Content/Rules for all slices
RTL | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTL
url |  | 1..1 | uri | "RTL"
RTL_Dose | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積劑量 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLDose
url |  | 1..1 | uri | "RTL_Dose"
RTL_NF | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積治療次數 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLnf
url |  | 1..1 | uri | "RTL_NF"
url |  | 1..1 | uri | "https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-EBRT-RTL"
value[x] |  | 0..0 |  |
Documentation for this format

Name | Flags | Card. | Type | Description & Constraints
--- | --- | --- | --- | ---
Extension |  | 0..* | Extension | 最高放射劑量臨床標靶體積、劑量以及治療次數
id |  | 0..1 | string | Unique id for inter-element referencing
Slices for extension |  | 3..* | Extension | Extension Slice: Unordered, Open by value:url
RTL | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTL
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
url |  | 1..1 | uri | "RTL"
value[x] | S | 1..1 | CodeableConcept | 較低放射劑量臨床標靶體積。[CRLF.rtl] Binding: 較低放射劑量臨床標靶體積值集 (required): 較低放射劑量臨床標靶體積；應填入所綁定值集中的其中一個代碼。
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
coding | S Σ | 1..* | Coding | Code defined by a terminology system
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
system | S Σ | 1..1 | uri | Identity of the terminology system
version | Σ | 0..1 | string | Version of the system - if relevant
code | S Σ | 1..1 | code | 最高放射劑量臨床標靶體積。[CRLF.rtl]
display | S Σ | 0..1 | string | Representation defined by the system
userSelected | Σ | 0..1 | boolean | If this coding was chosen directly by the user
text | S Σ | 0..1 | string | 最高放射劑量臨床標靶體積。[CRLF.rtl]
RTL_Dose | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積劑量 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLDose
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
url |  | 1..1 | uri | "RTL_Dose"
Slices for value[x] | S | 1..1 |  | 較低放射劑量臨床標靶體積劑量。[CRLF.rtl_dose] Slice: Unordered, Open by type:$this
valueBase64Binary |  |  | base64Binary |
valueBoolean |  |  | boolean |
valueCanonical |  |  | canonical(Any) |
valueCode |  |  | code |
valueDate |  |  | date |
valueDateTime |  |  | dateTime |
valueDecimal |  |  | decimal |
valueId |  |  | id |
valueInstant |  |  | instant |
valueInteger |  |  | integer |
valueMarkdown |  |  | markdown |
valueOid |  |  | oid |
valuePositiveInt |  |  | positiveInt |
valueString |  |  | string |
valueTime |  |  | time |
valueUnsignedInt |  |  | unsignedInt |
valueUri |  |  | uri |
valueUrl |  |  | url |
valueUuid |  |  | uuid |
valueAddress |  |  | Address |
valueAge |  |  | Age |
valueAnnotation |  |  | Annotation |
valueAttachment |  |  | Attachment |
valueCodeableConcept |  |  | CodeableConcept |
valueCoding |  |  | Coding |
valueContactPoint |  |  | ContactPoint |
valueCount |  |  | Count |
valueDistance |  |  | Distance |
valueDuration |  |  | Duration |
valueHumanName |  |  | HumanName |
valueIdentifier |  |  | Identifier |
valueMoney |  |  | Money |
valuePeriod |  |  | Period |
valueQuantity |  |  | Quantity |
valueRange |  |  | Range |
valueRatio |  |  | Ratio |
valueReference |  |  | Reference(Any) |
valueSampledData |  |  | SampledData |
valueSignature |  |  | Signature |
valueTiming |  |  | Timing |
valueContactDetail |  |  | ContactDetail |
valueContributor |  |  | Contributor |
valueDataRequirement |  |  | DataRequirement |
valueExpression |  |  | Expression |
valueParameterDefinition |  |  | ParameterDefinition |
valueRelatedArtifact |  |  | RelatedArtifact |
valueTriggerDefinition |  |  | TriggerDefinition |
valueUsageContext |  |  | UsageContext |
valueDosage |  |  | Dosage |
valueMeta |  |  | Meta |
value[x]:valueQuantity | S | 0..1 | Quantity | Value of extension
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
value | S Σ | 1..1 | decimal | Numerical value (with implicit precision)
comparator | ?!Σ | 0..1 | code | < | <= | >= | > - how to understand the value Binding: QuantityComparator (required): How the Quantity should be understood and represented.
unit | S Σ | 1..1 | string | Unit representation
system | S Σ C | 0..1 | uri | System that defines coded unit form Required Pattern: http://unitsofmeasure.org
code | S Σ | 0..1 | code | Coded form of the unit Required Pattern: centiGray
value[x]:valueCodeableConcept | S | 0..1 | CodeableConcept | Value of extension Binding: 較低放射劑量臨床標靶體積劑量值集 (required): 較低放射劑量臨床標靶體積劑量；應填入所綁定值集中的其中一個代碼。
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
coding | S Σ | 1..* | Coding | Code defined by a terminology system
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
system | S Σ | 1..1 | uri | Identity of the terminology system
version | Σ | 0..1 | string | Version of the system - if relevant
code | S Σ | 1..1 | code | Symbol in syntax defined by the system
display | S Σ | 0..1 | string | Representation defined by the system
userSelected | Σ | 0..1 | boolean | If this coding was chosen directly by the user
text | S Σ | 0..1 | string | Plain text representation of the concept
RTL_NF | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積治療次數 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLnf
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
url |  | 1..1 | uri | "RTL_NF"
Slices for value[x] | S | 1..1 |  | 較低放射劑量臨床標靶體積治療次數。[CRLF.rtl_nf] Slice: Unordered, Closed by type:$this
valueCodeableConcept |  |  | CodeableConcept |
valueQuantity |  |  | Quantity |
value[x]:valueQuantity | S | 0..1 | Quantity | Value of extension
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
value | S Σ | 1..1 | decimal | Numerical value (with implicit precision)
comparator | ?!Σ | 0..1 | code | < | <= | >= | > - how to understand the value Binding: QuantityComparator (required): How the Quantity should be understood and represented.
unit | S Σ | 1..1 | string | Unit representation
system | S Σ C | 0..1 | uri | System that defines coded unit form Required Pattern: http://unitsofmeasure.org
code | S Σ | 0..1 | code | Coded form of the unit Required Pattern: centiGray
value[x]:valueCodeableConcept | S | 0..1 | CodeableConcept | Value of extension Binding: 較低放射劑量臨床標靶體積治療次數值集 (required): 最高放射劑量臨床標靶體積治療次數；應填入所綁定值集中的其中一個代碼。
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
coding | S Σ | 1..* | Coding | Code defined by a terminology system
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
system | S Σ | 1..1 | uri | Identity of the terminology system
version | Σ | 0..1 | string | Version of the system - if relevant
code | S Σ | 1..1 | code | Symbol in syntax defined by the system
display | S Σ | 0..1 | string | Representation defined by the system
userSelected | Σ | 0..1 | boolean | If this coding was chosen directly by the user
text | S Σ | 0..1 | string | Plain text representation of the concept
url |  | 1..1 | uri | "https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-EBRT-RTL"
Documentation for this format

This structure is derived from Extension

Summary

Complex Extension: 用於表示癌症登記長表資料檔(CRLF)之較低放射劑量臨床標靶體積、劑量以及治療次數

- RTL: CodeableConcept: An Extension
- RTL_Dose: base64Binary, boolean, canonical, code, date, dateTime, decimal, id, instant, integer, markdown, oid, positiveInt, string, time, unsignedInt, uri, url, uuid, Address, Age, Annotation, Attachment, CodeableConcept, Coding, ContactPoint, Count, Distance, Duration, HumanName, Identifier, Money, Period, Quantity, Range, Ratio, Reference, SampledData, Signature, Timing, ContactDetail, Contributor, DataRequirement, Expression, ParameterDefinition, RelatedArtifact, TriggerDefinition, UsageContext, Dosage, Meta: An Extension
- RTL_NF: CodeableConcept, Quantity: An Extension

Differential View

This structure is derived from Extension

Name | Flags | Card. | Type | Description & Constraints
--- | --- | --- | --- | ---
Extension |  | 0..* | Extension | 最高放射劑量臨床標靶體積、劑量以及治療次數
extension |  | 3..* | Extension | Extension
Slices for extension |  |  |  | Content/Rules for all slices
RTL | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTL
url |  | 1..1 | uri | "RTL"
RTL_Dose | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積劑量 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLDose
url |  | 1..1 | uri | "RTL_Dose"
RTL_NF | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積治療次數 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLnf
url |  | 1..1 | uri | "RTL_NF"
url |  | 1..1 | uri | "https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-EBRT-RTL"
value[x] |  | 0..0 |  |
Documentation for this format

Snapshot View

Name | Flags | Card. | Type | Description & Constraints
--- | --- | --- | --- | ---
Extension |  | 0..* | Extension | 最高放射劑量臨床標靶體積、劑量以及治療次數
id |  | 0..1 | string | Unique id for inter-element referencing
Slices for extension |  | 3..* | Extension | Extension Slice: Unordered, Open by value:url
RTL | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTL
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
url |  | 1..1 | uri | "RTL"
value[x] | S | 1..1 | CodeableConcept | 較低放射劑量臨床標靶體積。[CRLF.rtl] Binding: 較低放射劑量臨床標靶體積值集 (required): 較低放射劑量臨床標靶體積；應填入所綁定值集中的其中一個代碼。
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
coding | S Σ | 1..* | Coding | Code defined by a terminology system
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
system | S Σ | 1..1 | uri | Identity of the terminology system
version | Σ | 0..1 | string | Version of the system - if relevant
code | S Σ | 1..1 | code | 最高放射劑量臨床標靶體積。[CRLF.rtl]
display | S Σ | 0..1 | string | Representation defined by the system
userSelected | Σ | 0..1 | boolean | If this coding was chosen directly by the user
text | S Σ | 0..1 | string | 最高放射劑量臨床標靶體積。[CRLF.rtl]
RTL_Dose | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積劑量 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLDose
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
url |  | 1..1 | uri | "RTL_Dose"
Slices for value[x] | S | 1..1 |  | 較低放射劑量臨床標靶體積劑量。[CRLF.rtl_dose] Slice: Unordered, Open by type:$this
valueBase64Binary |  |  | base64Binary |
valueBoolean |  |  | boolean |
valueCanonical |  |  | canonical(Any) |
valueCode |  |  | code |
valueDate |  |  | date |
valueDateTime |  |  | dateTime |
valueDecimal |  |  | decimal |
valueId |  |  | id |
valueInstant |  |  | instant |
valueInteger |  |  | integer |
valueMarkdown |  |  | markdown |
valueOid |  |  | oid |
valuePositiveInt |  |  | positiveInt |
valueString |  |  | string |
valueTime |  |  | time |
valueUnsignedInt |  |  | unsignedInt |
valueUri |  |  | uri |
valueUrl |  |  | url |
valueUuid |  |  | uuid |
valueAddress |  |  | Address |
valueAge |  |  | Age |
valueAnnotation |  |  | Annotation |
valueAttachment |  |  | Attachment |
valueCodeableConcept |  |  | CodeableConcept |
valueCoding |  |  | Coding |
valueContactPoint |  |  | ContactPoint |
valueCount |  |  | Count |
valueDistance |  |  | Distance |
valueDuration |  |  | Duration |
valueHumanName |  |  | HumanName |
valueIdentifier |  |  | Identifier |
valueMoney |  |  | Money |
valuePeriod |  |  | Period |
valueQuantity |  |  | Quantity |
valueRange |  |  | Range |
valueRatio |  |  | Ratio |
valueReference |  |  | Reference(Any) |
valueSampledData |  |  | SampledData |
valueSignature |  |  | Signature |
valueTiming |  |  | Timing |
valueContactDetail |  |  | ContactDetail |
valueContributor |  |  | Contributor |
valueDataRequirement |  |  | DataRequirement |
valueExpression |  |  | Expression |
valueParameterDefinition |  |  | ParameterDefinition |
valueRelatedArtifact |  |  | RelatedArtifact |
valueTriggerDefinition |  |  | TriggerDefinition |
valueUsageContext |  |  | UsageContext |
valueDosage |  |  | Dosage |
valueMeta |  |  | Meta |
value[x]:valueQuantity | S | 0..1 | Quantity | Value of extension
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
value | S Σ | 1..1 | decimal | Numerical value (with implicit precision)
comparator | ?!Σ | 0..1 | code | < | <= | >= | > - how to understand the value Binding: QuantityComparator (required): How the Quantity should be understood and represented.
unit | S Σ | 1..1 | string | Unit representation
system | S Σ C | 0..1 | uri | System that defines coded unit form Required Pattern: http://unitsofmeasure.org
code | S Σ | 0..1 | code | Coded form of the unit Required Pattern: centiGray
value[x]:valueCodeableConcept | S | 0..1 | CodeableConcept | Value of extension Binding: 較低放射劑量臨床標靶體積劑量值集 (required): 較低放射劑量臨床標靶體積劑量；應填入所綁定值集中的其中一個代碼。
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
coding | S Σ | 1..* | Coding | Code defined by a terminology system
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
system | S Σ | 1..1 | uri | Identity of the terminology system
version | Σ | 0..1 | string | Version of the system - if relevant
code | S Σ | 1..1 | code | Symbol in syntax defined by the system
display | S Σ | 0..1 | string | Representation defined by the system
userSelected | Σ | 0..1 | boolean | If this coding was chosen directly by the user
text | S Σ | 0..1 | string | Plain text representation of the concept
RTL_NF | S | 1..1 | (Complex) | 較低放射劑量臨床標靶體積治療次數 URL: https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-RTLnf
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
url |  | 1..1 | uri | "RTL_NF"
Slices for value[x] | S | 1..1 |  | 較低放射劑量臨床標靶體積治療次數。[CRLF.rtl_nf] Slice: Unordered, Closed by type:$this
valueCodeableConcept |  |  | CodeableConcept |
valueQuantity |  |  | Quantity |
value[x]:valueQuantity | S | 0..1 | Quantity | Value of extension
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
value | S Σ | 1..1 | decimal | Numerical value (with implicit precision)
comparator | ?!Σ | 0..1 | code | < | <= | >= | > - how to understand the value Binding: QuantityComparator (required): How the Quantity should be understood and represented.
unit | S Σ | 1..1 | string | Unit representation
system | S Σ C | 0..1 | uri | System that defines coded unit form Required Pattern: http://unitsofmeasure.org
code | S Σ | 0..1 | code | Coded form of the unit Required Pattern: centiGray
value[x]:valueCodeableConcept | S | 0..1 | CodeableConcept | Value of extension Binding: 較低放射劑量臨床標靶體積治療次數值集 (required): 最高放射劑量臨床標靶體積治療次數；應填入所綁定值集中的其中一個代碼。
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
coding | S Σ | 1..* | Coding | Code defined by a terminology system
id |  | 0..1 | string | Unique id for inter-element referencing
extension |  | 0..* | Extension | Additional content defined by implementations Slice: Unordered, Open by value:url
system | S Σ | 1..1 | uri | Identity of the terminology system
version | Σ | 0..1 | string | Version of the system - if relevant
code | S Σ | 1..1 | code | Symbol in syntax defined by the system
display | S Σ | 0..1 | string | Representation defined by the system
userSelected | Σ | 0..1 | boolean | If this coding was chosen directly by the user
text | S Σ | 0..1 | string | Plain text representation of the concept
url |  | 1..1 | uri | "https://www.ghd.tw/cdm-fhir/fhir/StructureDefinition/CRLF-EBRT-RTL"
Documentation for this format

This structure is derived from Extension

Summary

Complex Extension: 用於表示癌症登記長表資料檔(CRLF)之較低放射劑量臨床標靶體積、劑量以及治療次數

- RTL: CodeableConcept: An Extension
- RTL_Dose: base64Binary, boolean, canonical, code, date, dateTime, decimal, id, instant, integer, markdown, oid, positiveInt, string, time, unsignedInt, uri, url, uuid, Address, Age, Annotation, Attachment, CodeableConcept, Coding, ContactPoint, Count, Distance, Duration, HumanName, Identifier, Money, Period, Quantity, Range, Ratio, Reference, SampledData, Signature, Timing, ContactDetail, Contributor, DataRequirement, Expression, ParameterDefinition, RelatedArtifact, TriggerDefinition, UsageContext, Dosage, Meta: An Extension
- RTL_NF: CodeableConcept, Quantity: An Extension

Other representations of profile: CSV, Excel, Schematron

#### Terminology Bindings

Path | Conformance | ValueSet | URI
Extension.extension:RTL.value[x] | required | CRLFRTL (a valid code from 較低放射劑量臨床標靶體積代碼系統) `https://www.ghd.tw/cdm-fhir/fhir/ValueSet/CRLF-RTL` from this IG
Extension.extension:RTL_Dose.value[x]:valueQuantity.comparator | required | QuantityComparator `http://hl7.org/fhir/ValueSet/quantity-comparator|4.0.1` from the FHIR Standard
Extension.extension:RTL_Dose.value[x]:valueCodeableConcept | required | CRLFRTLDoseValueSet (a valid code from 較低放射劑量臨床標靶體積劑量代碼系統) `https://www.ghd.tw/cdm-fhir/fhir/ValueSet/CRLF-RTLDose` from this IG
Extension.extension:RTL_NF.value[x]:valueQuantity.comparator | required | QuantityComparator `http://hl7.org/fhir/ValueSet/quantity-comparator|4.0.1` from the FHIR Standard
Extension.extension:RTL_NF.value[x]:valueCodeableConcept | required | CRLFRTLNFValueSet (a valid code from 較低放射劑量臨床標靶體積治療次數代碼系統) `https://www.ghd.tw/cdm-fhir/fhir/ValueSet/CRLF-RTL-NF` from this IG

#### Constraints

Id | Grade | Path(s) | Details | Requirements
ele-1 | error | **ALL** elements | All FHIR elements must have a @value or children : hasValue() or (children().count() > id.count()) |
ext-1 | error | **ALL** extensions | Must have either extensions or value[x], not both : extension.exists() != value.exists() |
